Water rocket fleet

ROCKET FLEET

This is a list of all our water rockets since 2013 including many technical details and pictures. Please note that the rockets of JCA and DTMS are separated until May 2016. You can click on the rockets to learn more about them.

UEBERFLIEGER MINI EVO

First launch: 6th May 2016

Apollinaris 1 L radial - 6.7 L 610 g 91 g / L 16.5 bar / 240 psi 1 L

DTMS

Highest flight: 951 feet

UEBERFLIEGER EVO

First launch: 6th June 2016

Apollinaris 1 L radial - 8.55 L 745 g 87 g / L 16.5 bar / 240 psi 1.15 L

DTMS

ARROW 2

First launch: 16th October 2016 3rd June 2017 (rebuild)

Apollinaris 1 L to the side - 7.1 L 630 g 89 g / L 15.5 bar / 225 psi (tested) 1.1 L

JCA

ARROW 1

First launch: 28th May 2016

Apollinaris 1 L to the side - 4.6 L 445 g 97 g / L 16 bar / 230 psi 1.2 L

JCA

ARROW 3

First launch: 16th October 2016

Apollinaris 1 L to the side - 9.2 L 821 g 89 g / L 15 bar / 220 psi (tested) 1.7 L

JCA

FALCON 1

First launch: 22nd September 2016

Used bottle type: Parachute ejection: Height: Volume: Weight: Weight / Volume: Max. pressure: Optimal amount of water:

Aloisius Quelle 0.5 L to the top - 4.68 L 555 g 119 g / L 16.5 bar / 240 psi (tested) 0.85 L

DTMS

FALCON 2

First launch: 22nd December 2016

Aloisius Quelle 0.5 L to the top 2.07 m 6.12 L 690 g 113 g / L 18 bar / 260 psi (tested) 1 L

DTMS

UEBERFLIEGER MINI (G)

First launch: 13th December 2015 12th February 2016

DTMS

Highest flight: 630 feet 912 feet

UEBERFLIEGER (G)

First launch: 2nd May 2015 6th December 2015

DTMS

Highest flight: 577 feet -

ÜBERFLIEGER 2 (G)

First launch: 7th June 2015 10th April 2016

Apollinaris 1 L radial - 9.91 l 626 g 64 g / L 8.5 bar / 120 psi 1.85 L

DTMS

Highest flight: 702 feet -

Apollinaris 1 L radial - 9.91 L 855 g 86 g / L 16.5 bar / 240 psi 1.4 L

Apollinaris 1 L radial - 7.9 l 540 g 68 g / L 8.5 bar / 120 psi 1.55 L

Apollinaris 1 L radial - 7.9 l 733 g 93 g / L 16.5 bar / 240 psi 1.15 L

Apollinaris 1 L radial - 6.1 l 465 g 76 g / L 8.5 bar / 120 psi 1.53 L

Apollinaris 1 L radial - 6.1 l 570 g 93 g / L 16.5 bar / 240 psi 1.53 L

SWALLOW 1

First launch: 4th January 2014

Apollinaris 1 L to the side - 6.4 L 720 g 113 g / L 9 bar / 130 psi 2.1 L

JCA

SKYHOPSER 1

First launch: 4th October 2013

Apollinaris 1 L to the side - 2.8 L 310 g 111 g / L 9 bar / 130 psi 0.9 L

JCA

Highest flight: -

SKYHOPSER 2(R)

First launch: 23rd July 2014 28th February 2015

JCA

Highest flight: - 685 feet

FIP

First launch: 25th March 2015

DTMS

Highest flight: 456 feet

Apollinaris 1 L radial - 3.5 l 325 g 93 g / L 9 bar / 130 psi 0.9 L

Apollinaris 1 L to the side - 4.3 l 380 g 88 g / L 9 bar / 130 psi 1.3 L

Apollinaris 1 L to the side - 4.3 l 480 g 109 g / L 16 bar / 230 psi 1.1 L

If you are interested in our oldtimers, check out the following PDF. It is only available in German but you will be able to understand all the relevant data. :)

EVEN OLDER ROCKETS 2011 - 2013 | JCA (GERMAN)

PDF

Highest flight: -

Used bottle type: Parachute ejection: Height: Volume: Weight: Weight / Volume: Max. pressure: Optimal amount of water:

FALCON MINI

First launch: 10th May 2017

DTMS

Highest flight: 945 feet

Used bottle type: Parachute ejection: Height: Volume: Weight: Weight / Volume: Max. pressure: Optimal amount of water:

Aloisius Quelle 0.5 L to the top 1.4 m 4.0 L 450 g 113 g / L 17 bar / 250 psi 0.7 L

ROCKETS SINCE MAY 2016

ROCKETS BY JCA SINCE 2013

ROCKETS BY DTMS SINCE 2015
